Garantie la toate produseleINVERTER OUTPUT
Rated Power: 3000VA / 3000W
Surge Power: 6000VA
Waveform: Pure sine wave
AC Voltage Regulation (Batt.Mode): 220VAC~240VAC(Setting)
Inverter Efficiency(Peak): 90%~93%
Transfer Time: 10ms(UPS / VDE4105) / 20ms(APL)
AC INPUT
Voltage: 230VAC
Selectable Voltage Range: 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range: 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage: 24VDC
Floating Charge Voltage: 27.4VDC
Overcharge Protection: 30VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage: 145VDC
PV Array MPPT Voltage Range: 30~120VDC
Standby Power Consumption: 2W
Maximum PV Array Power: 1500W
Maximum Solar Charge Current: 60A
Maximum Efficiency: 98%
Maximum AC Charge Current: 20A or 30A
Maximum Charge Current: 80A
MECHANICAL SPECIFICATIONS
Machine Dimensions (W*H*D)(mm): 272*355*100
Package Dimensions (W*H*D)(mm): 485*393*251
Net Weight(kg): 7.4
Gross Weight(kg): 9.5
OTHER
Humidity: 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature: 0°C~50°C
Storage Temperature: -15°C -60°C
